Cubicle Spaces Private Limited

CS Silvanus(Aluminum with SS)

PRODUCT DESCRIPTION

CS Silvanus(Aluminum with SS) is developed for providing higher endurance and spectacular design. Magnificent design united with great functional features makes it an innovative restroom series offering uncompromised quality at an economical price along with extraordinary benefits. Engineered with 12mm or 18mm thick high pressure Compact Laminate, this model comes with the combination of stainless steel hardwares with extruded anodised aluminum top rail and fixing channels. Thus, it’s a valuable choice for users who desire a highly adaptable restroom space, preferred across the globe for its budget effective product detailing and matchless quality.

Stainless Steel Top

Alloy Privacy Indicator

Stainless Steel Adjustable Leg

Coat Hook

Hardware Fixing Details

The adjustable foot that supports the pilasters is made from stainless steel (Grade 304) and its base is anchored to the floor with nylon plug, fixed into ground with stainless steel screws. There is a ground clearance of 150 mm. Stainless Steel U-channels are used to attach with the divider panels to the wall as well as the mid panel with stainless steel (Grade 304) screw inserts. Stainless Steel top rail coated in stainless steel colour is used to fix the pilasters at the top. Doors are incorporated with the noise deafening tape to reduce the noise effect. All other fittings like hinges, coat hook, adjustable foot and lock set/latch indicator is manufactured in stainless steel.

Hardware Detailing

Each restroom cubicle is equipped with the following set of hardware fittings:

F Channel
(Alumunium Powder
Coated)
U Channel
(Alumunium Powder
Coated)
TopRail
(Alumunium Powder
Coated)
Coat Hook
(Stainless Steel 304)
Wc Indicator Lock
(Stainless Steel 304)
Door Knob
(Stainless Steel 304)
Auto Gravity Hinges
(Stainless Steel 304)
Door Stopper
(Stainless Steel 304)
Adjustable leg
(Stainless Steel 316)

Dimensions Detailing

Standard Dimensions General (mm) Physically Challenged (mm)
Width of cubicle 1000 1500
Depth of cubicle 1500 1750
Height of entire cubicle 2000 2000
Width of door 600 900
Height of door 1785 1785
Ground clearance 150 150
